Details
Details
- Brand:
- SKU:
355109172
- GTIN: 04082300573237
- UPC: 082300573237
- Positions: Front
- Description: HELLA PAGID Brake Discs are designed to precisely reflect the requirements of various vehicle types, brake systems, engine outputs, driving loads, and braking characteristics.
Disc Brake Rotor
BRK DISC ROT
Saab 9-3 2011-2003, 9-3X 2011-2010 - Condition: New
Additional Information
Additional Information
| ABS Tone Ring Included | No |
| Assy./disassy. by qualified personnel required! | . |
| Balancing Type | Mill Balancing |
| Bearings Included | No |
| Bolt Hole Circle Ø [in] | 4.33 |
| Bolt Hole Circle Ø [mm] | 110 |
| Brake Disc Thickness [in] | 1.10 |
| Brake Disc Thickness [mm] | 28 |
| Brake Disc Type | Externally Vented |
| Center Hole Diameter | 98.0 |
| Centering Diameter [in] | 2.76 |
| Centering Diameter [mm] | 70 |
| Construction | Full Cast |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Disc Finish | coated |
| Discard Thickness | 25.00 |
| Grade Type | Regular |
| Hat Finish | coated |
| Height [in] | 1.77 |
| Height [mm] | 45 |
| Hole Arrangement/Number | 05/08 |
| Inner diameter [mm] | 139.1 |
| Inside Diameter | 70.0 |
| Machining | High-Carbon |
| Material | gray cast iron |
| Minimum thickness [in] | 0.98 |
| Minimum thickness [mm] | 25 |
| Mounting Bolt Hole Circle Diameter | 110.00 |
| Mounting Bolt Hole Quantity | 8 |
| Nominal Thickness | 28.00 |
| Number of bolts/screws | 1 |
| Outer Diameter [in] | 11.89 |
| Outer diameter [mm] | 302 |
| Outside Diameter | 302.00 |
| Overall Height | 45.00 |
| Rust Resistant Coating | Yes |
| Solid Or Vented Type Rotor | Vented |
| Supplementary Article/Info 2 | without Wheel Hub |
| Surface | Coated |
| Surface Type | Smooth |
| Technical Information Number | 54183PRO_HC_NA |
| UPC | 04082300573237 |
| Weight [kg] | 8.5 |
| Wheel Bolt Bore Ø [mm] | 14.2 |
